产品介绍
Welldisk W30S34符合JEDEC MO-300A规范，并通过了严格测试，可应用在工业计算机与嵌入式相关等产品。W30S34系列适用于0到70°C的工作环境；另也有支持宽温的版本，在-40°C到85°C的严苛环境下也能正常运作。此外，所有Welldisk的固态硬盘，均需通过Welldisk自行开发的SSD验证测试机制，对产品进行功能性、效能测试(Functionality test)，和可靠度验证 (Reliability Validation) ，为质量做到最严谨的把关，确保最高的稳定性。
规格
|
容量
|
64GB~2TB
|
|
尺寸 (长 x 宽 x 高)
|
50.95 x 30 x 4.75mm
|
|
界面
|
MO-300A mSATA
|
|
工作电压
|
3.3V
|
|
耗电量
|
2W
|
|
防震能力
|
1500G/0.5ms
|
|
Operating Humidity
|
5%~95%
|
|
Flash Type
|
3D TLC
|
|
Sequential Read (Max*)
|
430MB/s
|
|
Sequential Write (Max*)
|
130MB/s
|
|
Data Transfer Mode
|
SATA III 6Gbps
|
|
Operating temperature (Industrial)
|
-40°C to 85°C
|
|
Operating temperature (Commercial)
|
0°C to 70°C
|
|
Vibration Resistance
|
20G (80-2000Hz)
|
|
S.M.A.R.T.
|
S.M.A.R.T , A+ SLC Mode, Write Protection, Quick Erase
|
|
Features
|
S.M.A.R.T.; Write Protection; A+SLC Mode; Quick Erase
|
订购信息
| W30S34-064GC |
|
MSATA |
3D TLC |
64GB |
-40°C to +85°C |
|
| W30S34-128GC |
|
MSATA |
3D TLC |
128GB |
-40°C to +85°C |
|
| W30S34-256GC |
|
MSATA |
3D TLC |
256GB |
-40°C to +85°C |
|
| W30S34-512GC |
|
MSATA |
3D TLC |
512GB |
-40°C to +85°C |
|
| W30S34-001TC |
|
MSATA |
3D TLC |
1TB |
-40°C to +85°C |
|
| W30S34-002TC |
|
MSATA |
3D TLC |
2TB |
-40°C to +85°C |
|
| W30S34-064GD |
|
MSATA |
3D TLC |
64GB |
0°C to +70°C |
|
| W30S34-128GD |
|
MSATA |
3D TLC |
128GB |
0°C to +70°C |
|
| W30S34-256GD |
|
MSATA |
3D TLC |
256GB |
0°C to +70°C |
|
| W30S34-512GD |
|
MSATA |
3D TLC |
512GB |
0°C to +70°C |
|
| W30S34-001TD |
|
MSATA |
3D TLC |
1TB |
0°C to +70°C |
|
| W30S34-002TD |
|
MSATA |
3D TLC |
2TB |
0°C to +70°C |
|
Data Sheet
|
| W30S34-XXXXX |
|
2017-06-21 10:43:51 |
 |
